LED CONNECTIONS
Figure 4: JIB-4000 LED Rear Connections
Pin
Signal
1
LED common anode (3.3 V d.c.)
2
LED 1 cathode
3
LED 2 cathode
Figure 5: LED connection mating plug
Pin 1
