7/68
1. Remove the cap, nozzle and lter.
2. Mount the calibrator cover to the lance.
3. Reinstall the lter, nozzle and cap.
4. Screw the calibrator onto the cover.
Record the time it takes to
walk 25 m²
Simulate the spraying of 25 m²
• Hold the lance at the normal working height and spray into
the bottle while walking the distance required to spray an
area corresponding to 25 m².
• Place the bottle on a level surface and observe the liquid level
visible through the side of the bottle. Match the liquid level to
the corresponding scale on the calibrator bottle.
• Empty the bottle and repeat this operation to determine the
average of two or more readings.
4.3. Choosing nozzle type
Seven main nozzle designs are used on knapsack sprayers. Each
nozzle design is available in a range of sizes to optimize the use
of product to be applied. The nozzle choice will be based on the
agrochemical type to be used and the droplet size recommend-
ed (table):
WARNING!
Wear a protective clothes to do the mainte-
nance and parts replacement.
NOTE: For the volume in liters per bushel (L / alk), simply multiply
the value obtained in liters per hectare (L / ha) by 2.42.
NOTE: This sprayer is packaged with Blue Adjustable Cone noz-
zle tted in the lance. Other nozzles mentioned in this manual
are optional, so they do not accompany this sprayer.
IDENTIFICATION
(Part no. - Description)
FILTER (Mesh)
NOZZLE
TYPE
(1197536) JEF 11002
YELLOW
(1197476) JSF 11002
YELLOW
(1197535) JEF 110015
GREEN
80 (Zinc yellow)
50(Gentian blue)
50(Gentian blue)
80 (Zinc yellow)
50(Gentian blue)
50(Gentian blue)
50(Gentian blue)
50(Gentian blue)
50(Gentian blue)
50(Gentian blue)
50(Gentian blue)
50(Gentian blue)
80 (Zinc yellow)
80 (Zinc yellow)
50(Gentian blue)
(1197475) JSF 110015
GREEN
(1197537) JEF11003
BLUE
(1197477) JSF11003
BLUE
Herbicides
30
30
0.49
0.49
30
30
0.65
0.65
30
30
0.58
0.98
APPLICATION
PRESSURE
(psi)
FLOW RATE
(l/min)
(1197565) JHC 8002
YELLOW
45 0.80
(1198892) JHC 8004
RED
45 1.60
(1198893) JHC 8005
BROWN
45
2.00
(1197486) JDF 04
RED
(1197497) JAI 120015
GREEN
(1197488) JDF 06
GREY
(1197501) JAI 12003
BLUE
(1197487) JDF 05
BROWN
(1197499) JAI 12002
YELLOW
15
20
0.92
0.42
15
20
1.15
0.57
15
20
1.39
0.85
Fungicide,
insecticide
and
foliar
fertilizers
Herbicides
and
foliar
fertilizers
Herbicides
Herbicides
Recommended Acceptable Not recommended
Nozzle
Herbi-
cide
Fungi-
cide
Insec-
ticide
Code Name Picture
1197571 JHC
217174 JD-12
1197537 JEF
1197477 JSF
325787 J ADJ
1197486 JDF
1197486 JAI
Prevent the ow rate to be higher than 10% of the nozzle nom-
inal ow rate.
It is recommended to use the pressure and ow rate regulating
valve (ECOVALVE) in order to achieve a more accurate spraying
method.
