ACC (Accessory)
The ACC (Accessory) switch controls these func-
tions in the continuous sequence indicated:
1. OFF
2. AIR
3. AIR/LIGHT
4. LIGHT
When the AIR (blower function is activated, thejets
will tyrn off if they have been selected by the SYSTEM
switch. Activating the AIR function will also turn off the
heater if the HTR/FLTR function has been activated by
the SYSTEM switch. (If the unit is properly converted to
230 VAC 50 Amp, 4—wire, no overriding of features will
exist.)
OPERATION
10
Controls
A switch panel giving you convenient control of the
jets, filter, heater/filter, light and air blower is located on
the spa rim.
To ensure your safety and allow easy operation,
your spa is equipped with two air-activated switches.
One, the SYSTEM switch, controls the whirlpool jets,
heat, and filtration. The other switch, ACC (Accessory)
controls the air blower and optional light.
Refer to the Control Panel illustration for an explana-
tion of the various switch functions.
SYSTEM
The SYSTEM switch controls the following four
functions in the continuous sequence indicated:
1. OFF
2. JETS
3. HTR/FILTER
4. FILTER
(The next selection is OFF again.)
Use the JETS function as a reference to indicate
your location in the function sequence, since that func-
tion is the most obvious when operating.
For best performance and increased equipment life,
pause a second or two between push-button selec-
tions. Not pausing may cause the switch to malfunction.
TEMPERATURE CONTROL KNOB
(for adjusting thermostat)
SYSTEM SWITCH
(Controls Whirlpool, Heater/
Filter and Filter only functions.)
AIR INDUCTION
(Controls Air Blower
and Light Functions)
H
E
A
T
E
R
S
Y
S
T
E
M
J
E
T
S
F
I
L
T
E
R
H
T
R
/
F
L
T
R
O
F
F
HEATER
INDICATOR
LIGHT
CONTROL PANEL
TEMPERATURE
CONTROL
KNOB
SYSTEM
SWITCH
ACCESSORY
SWITCH
SILENT AIR
INDUCTION
CONTROLS
