SECTION 4. GENERAL
CLEANER
INFORMATION
CAUTION
To prevent damage to the cleaner, to adhere to the
following guidelines:
• Remove the cleaner from the pool after the cleaning
cycle is completed.
• Store out of direct sunlight or inclement weather.
• Never lift the cleaner out of the pool by the oating
cable.
• Take additional care when lifting the cleaner out of the
pool. It becomes heavier when lled with water.
• Always remove the cleaner from pool when super
chlorinating or adding acid.
• Do not handle cleaner while it is in operation
IMPORTANT
• Always fully submerge the cleaner head before you
begin operation.
• Clean the lter canister after each cleaning cycle.
• Do not leave your cleaner in the pool on a
permanent basis.
• At the end of each cycle, remove the cleaner from
the pool.
• Start at the cleaner head and untangle any coils in
the cable before storing the cleaner.
The robotic cleaner includes a safety feature that
automatically stops the cleaner if a cleaning cycle starts
but it is not submerged in water. For pools equipped
with a beach area, this safety feature is programmed
to drive the cleaner in reverse and back into the pool
when the impeller is out of the water.
4.1 INSTALL AND SUBMERGE THE
CLEANER
1. With the control box plugged into a power
outlet, spread the oating cable across the pool
deck until you reach the middle of the pool
length.
WARNING: Do not use an extension cord
2. At the center point, submerge the cleaner in
the pool and hold in the vertical position to
release any air trapped inside.
(Figure 3).
1
Figure 3. Submerge the Cleaner Vertically
3. Ensure the unit sinks to the bottom of the pool
and does not oat (Figure 4).
2
Figure 4. Cleaner Sinking to the Bottom of the
Pool
7
OWNER'S MANUAL
