It is the responsibility of the installer/owner to ascertain
compliance with specic local regulations prior to installa-
tion. Jacuzzi Europe S.p.A. gives no guarantee in this respect
and declines all responsibility regarding the compliance of
the installation performed.
Technical Features
Flow comes with a 2 Hp pump and a recirculation pump.
Flow is equipped with a cartridge lter that ensures excellent
water ltering (ltering surface: 4.6 m
2
).
Maximum absorption of the system
• VERSION WITH HEATER 2 KW
Power supply (x)
Total consumption
· electric heater + hydromassage + ltering
Audio System
(optional)
Voltage
220-240 ~ 50/60 17,5 (k) 4,0 (j) 0,25 (j)
Hertz Ampere kW kW
• VERSION WITH HEATER 1,5 KW
Power supply (x)
Total consumption
· electric heater + ltering
· only hydromassage
Audio System
(optional)
Voltage
220-240 ~ 50/60 8 (k) 1,8 (j) 0,25 (j)
Hertz Ampere kW kW
(k): at 230 V - (j): absorbed power
(x): see “Electrical preparations”
The electrical system that powers the spa must absolutely be
sized for maximum consumption (as shown in the table).
Weights
Net weight average ll water volume
MAX
Total max. weight
kg litres litres kg
~ 300 ~ 470 ~ 570 ~ 870
support area concentrated load
on support area
m
2
kg/m
2
~ 2,25 ~ 385
User safety
Q If installed by qualied personnel in compliance with the in-
structions in the enclosed installation manual, the system does
not present any risks for the user. However, safety is also contin-
gent upon appropriate use, according to the provisions in the
respective manual, while the user must delegate the operations
described in the installation manual to qualied personnel.
Q It is important to make sure that personnel tasked to install
or manage the system are qualied as per legal requirements in
eect in the country where installation is carried out.
QFor special maintenance operations and/or repairs, you should
always contact authorised Jacuzzi® service centres and use only
original spare parts.
Arrangement for installation
QFlow requires the following plumbing connections (arranged
as in
1 and 3):
- B: spa drain.
- C: connection of overow; to be made in the eld, after drilling
a hold in the bottom of the support base, depending on the type
of installation.
The customer must make provisions for a ground drainage point
of suitable dimensions and that can be inspected for any clean-
ing that may be required.
ATTENTION: Before preparing the ground drainage
point, consult the local authority for the regulations
that control the drainage of chemically treated water.
It is advisable to provide a drain system under the support
area of the spa which is connected to the main drain, con-
necting the main drain also to the tting present on the base
(2).
ATTENTION: Jacuzzi® advises against outdoor installa-
tion.
QTo periodically empty the spa you can:
- connect a pipe to the drain valve, after removing the plug and
screwing in the tting with gasket (included, 2, det. B).
NOTE: To open the valve, you must turn the ring nut anticlockwise
and pull it, therefore if you decide to connect the spa permanently
to the ground drainage point, we recommend you install a valve be-
low, bypassing the valve installed in the factory.
- where it is not possible to connect the spa permanently to the
ground drainage point, use a swimming pool portable pump.
QIt is possible to connect the drain and the overow together,
however after the gate valve (installed on the discharge tube)
since the overow must always be open.
QYou can use a garden hose to ll the spa.
If the spa is connected, for periodic lling, to the
mains system that supplies drinking water, this con-
nection must be carried out in compliance with the
EN1717 norm, using “AA”, “AB” or “AD” anti-pollution
protection procedures. For further information, we
recommend you contact your water supply company
and/or your plumber.
Flow can be installed resting on the oor or on a purposely set-
up base ( 4).
