J-100
Export Models (50 Hz) Service
Single Breaker
Service 1
(including Heater)*
Single Breaker
Service 1 (including
Heater)**
Voltage: 230 VAC 230 VAC
Max. Current Draw:
1-Pump System 17A 21A
2-Pump System 17A 21A
Wattage:
1-Pump System: 3.9 kW 4.8 kW
2-Pump System: 3.9 kW 4.8 kW
Frequency: 50 Hz 50 Hz
Number of Wires: 3 3
Single Breaker is the factory default.
* For this service, the heater will not operate while either jets pump is
running in high speed. The service 1 breaker will include connection for all
components. Note: pump 2 runs only in high speed.
** For this service, the heater will operate while one jets pump is running
in high speed. The service 1 breaker will include connection for all
components. Note: pump 2 runs only in high speed.
Export Models (50 Hz) Service
Dual Breaker
Service 1/
Service 2***
Three Phase Service
Service 1/
Service 2/Service 3****
Voltage: 230 VAC 230 VAC
Max. Current Draw:
1-Pump System 12A/9A N/A
2-Pump System 12A/16A 14A/7A/7A
Wattage:
1-Pump System: 2.8kW/2.1kW N/A
2-Pump System: 2.8kW/3.7kW 3.2kW/1.6kW/1.6kW
Frequency: 50 Hz 50 Hz
Number of Wires: 5 5
Single Breaker is the factory default.
*** For this service, the heater will operate while both jets pumps are running
in high speed. The service 1 breaker will include connections for the
heater and transformer. The service 2 breaker is for all other components.
Note: pump 2 runs only in high speed.
****
In this conguration, the heater will operate while both jets pumps are
running in high speed. The service 1 breaker will include connections for
the heater and transformer. Service 2 breaker is for pump 1 and other
components. Service 3 breaker is for pump 2.
13
