17
It is the responsibility of the installer/owner to ascertain
compliance with specic local regulations prior to installa-
tion.
Jacuzzi Europe S.p.A. gives no guarantee in this respect and
refuses all responsibility regarding compliance of the instal-
lation carried out.
Technical Features
The Premium spas feature a single-phase power supply (220-
240 V). All electro-mechanical parts and pipes are enclosed.
The models of the J-400 range have 1-2 hydromassage pumps
and a circulation pump.
Maximum absorption of the system
The electrical system that powers the spa must absolutely be
sized for maximum consumption (as shown in the table).
(k): a 230V
(single-phase)
(j): max. power
absorption
220-240 ~ 50 21
(k)
4,8
(j)
220-240 ~ 50 21
(k)
4,8
(j)
220-240 ~ 50 29
(k)
6,7
(j)
220-240 ~ 50 29
(k)
6,7
(j)
220-240 ~ 50 29
(k)
6,7
(j)
220-240 ~ 50 29
(k)
6,7
(j)
220-240 ~ 50 29
(k)
6,7
(j)
220-240 ~ 50 29
(k)
6,7
(j)
J-315
J-325
J-335
J-345
J-355
J-365
J-375
J-385
Power supply
(single-phase)
Tot. Consumption: electric
heater + pump(s)
Voltage Hertz Ampere kW
Volt 220-230 V ~ Hertz 50
16 A 32 A 16 A
16 A
(a) (b) (c)*
(a) (b) (c)*
(a) (b) (c)*
(a) (b) (c)*
(a) (b) (c)*
(a) (b) (c)*
(a) (b) (c)*
(a) (b) (c)*
J-315
J-325
J-335
J-345
J-355
J-365
J-375
J-385
Ampere
Breaker N°
1
2
(a) The conguration will include connection for pumps, circula-
tion pump, CLEARRAY, lighting, stereo (optional), ozone (optio-
nal) and heater.
(b) The conguration will include connection for pumps, circu-
lation pump, CLEARRAY, lighting, stereo (optional), ozone (op-
tional) and heater.
(c)* The main breaker will include connection for pumps, circu-
lation pump, CLEARRAY, lighting, stereo (optional), ozone (op-
tional). The secondary breaker will be used exclusively for the
heater. This is the factory default setting.
If sucient electrical energy is not available, an electronic ener-
gy consumption limiter can be activated from inside the electro-
nics box.
This operation can only be performed by authorized Jacuz-
zi® technicians and limits electricity consumption as follows:
(a) the heater will not operate while either jets pump is run-
ning.
(b) the heater will operate while two jets pump are running.
(c)* the heater will operate while both jets pump are running.
This is the factory default setting.
Refer to the relative user and maintenance manual. See “Dip
Switch Settings” chapter.
Weights
J-315
J-325
J-335
J-345
J-355
J-365
J-375
J-385
~ 259 ~ 871 ~ 1060
~ 1318 2,52 ~ 523
~ 312 ~ 1363 ~ 1666
~ 1976 3,33 ~ 593
~ 342 ~ 1363 ~ 1703
~ 2044 3,67 ~ 555
~ 374 ~ 1401 ~ 1741
~ 2114 3,67 ~ 574
~ 379 ~ 1514 ~ 1855
~ 2233 3,89 ~ 574
~ 394 ~ 1666 ~ 1893
~ 2285 3,89 ~ 587
~ 407 ~ 1779 ~ 2196
~ 2601 4,36 ~ 596
~ 415 ~ 1893 ~ 2196
~ 2610 4,36 ~ 598
net weight maximum
water volume
kg litres litres kg
average fill total
max. weight
support area
load concentrated
on support area
m kg/m
User safety
The system, if installed by qualied personnel, does not pre-
sent any hazard for the user. Safety is however also contingent
upon proper use, as set forth by the user’s manual included with
the product. The user must contact qualied personnel for spe-
cial operations described in the manual.
It is important to make sure that personnel tasked to install
and manage the system are qualied as per legal requirements
in eect in the country where installation is carried out.
Periodically, however, the dierential switch (see “Electrical
Safety” chapter) of the system to which the mini-pool is con-
nected must be checked for eciency. When you press the
TEST key, the switch must disconnect. If this does not hap-
pen, disconnect the power supply immediately and contact
a qualied technician.
For any extra maintenance and/or repairs it is recommended
that you contact an Authorized Service Centre and use only ori-
ginal spare parts.
Positioning the Jacuzzi remote monitoring system
Check the power level of your domestic Wi-Fi router in the loca-
tion where you want to install the spa.
If the router’s Wi-Fi signal is strong (3-4 bars) and internet access
is stable, it is an optimal location to install the spa. If it is weak, it
may be necessary to select another position or install a “repea-
ter” to make the signal stronger.
Refer to the relative user and maintenance manual.
Set up for installation
The customer must make provisions for a ground drainage
point of suitable dimensions and that can be inspected for any
cleaning that may be required.
