9.11 J-465 Massage/Waterfall Selector Diagram
Massage Selectors (1)
• Massageselector1divertsjetspumpNº1outputbetweenjetgroups
1a-1b.
Mass Aspiration Jet Flow Control Valve (2)
• Valve(2)controlsoutputtofootwellIXJet.
Waterfall Selector (3)
• Waterfallselector(3)controlscirculationpumpoutputtowaterfall.
Jets Without Massage Selector Controls (4)
• Jets(4)arealwaysonwhenjetspumpNº2isrunning.
