Jacuzzi J - 425 - J-415 Massage;Waterfall Selector Diagram

Page 42
J-400
9.20 J-415 Massage/Waterfall Selector Diagram
2
1a
1a
1a
1a
1b
1b
1b
2
b
a
1
Massage Selector (1)
• Massageselector1divertsoutputbetweenjetgroups1a-1b.
Waterfall Selector (2)
• Waterfallselector2controlscirculationpumpoutputtowaterfall.
