Jacuzzi J - 425 - J-460 Massage;Waterfall Selector Diagram

Page 36
J-400
9.14 J-460 Massage/Waterfall Selector Diagram
98
F
1
4
4
1a
4
4
4
3
3 2
2
Massage Selector (1)
• Massageselector1divertsjetspumpNº2outputbetweenjetgroups
1a-1b.
Mass Aspiration Jet Flow Control Valve (2)
• Valve(2)controlsoutputtofootwellIXJet.
Waterfall Selector (3)
• Waterfallselector(3)controlscirculationpumpoutputtowaterfall.
Jets Without Massage Selector Controls (4)
• Jets(4)arealwaysonwhenjetspumpNº1isrunning.
Spa operation subject to change without notice
