Jacuzzi J-585

Page 16
7.0 Power Requirements
Jacuzzi
®
spas are designed to provide optimum performance and
exibility of use when connected to their maximum electrical service.
They are congured at the factory. The most common electrical
connections are listed below. Reference page 73 for dip switch
settings.
• All North American 60 Hz Models only: These models come set for
50A logic. If you prefer, your qualied technician can perform a logic
modication that allows the spas to operate on a different electrical
service.
North American Models (60 Hz)
Voltage: 240 VAC 240 VAC 240 VAC
Max. Current Draw: 32A 40A 48A
Frequency: 60 Hz 60 Hz 60 Hz
Number of Wires: 3 3 3
Circuit Breaker (2-Pole): 40A* 50A** 60A***
*
In 40A conguration, the heater will not operate while either jets
pump is running.
**
In 50A conguration, the heater will operate when one jets pump
is running, but will not operate while both jets pumps are running.
This is the factory setting.
***
In 60A conguration the heater will operate while both jets pumps
are running.
• All Export 50 Hz Models:
Export Models (50 Hz)
Single Breaker Single Breaker
Service 1
(including heater)*
Service 1
(including heater)**
Voltage: 230 VAC 230 VAC
Max. Current Draw: 17A 30A
Wattage: 3,9 kW 6,9 kW
Frequency: 50 Hz 50 Hz
Number of Wires: 3 3
*
In this conguration, the heater will not operate while either jets pump is
running. Only one jets pump will operate at a time.
**
In this conguration, the heater will operate while both jets pumps are
running.
