Page 17
Export Models (50 Hz)
Dual Service Breakers
Service1/Service 2**
Three Phase Service
Service1/Service 2/
Service 3***
Voltage: 230 VAC 230 VAC
Max. Current Draw: 12A/17A 12A/7A/10A
Wattage: 2,8kW/3,9 kW 2,8kW/1,6kW/2,3kW
Frequency: 50 Hz 50 Hz
Number of Wires: 5 5
**
In this conguration, the heater will operate while both jets pumps are
running. The Service 1 breaker will include connections for the heater
and transformer. The Service 2 breaker will have connections for all other
components. Note: 1x16A/20A is the factory setting.
***
In this conguration, the heater will operate while both jets pumps are
running. The Service 1 breaker will include the connection for the heater
and transformer. The Service 2 breaker (B) will have the connection for
jets pump 2. The Service 3 breaker (C) will have connections for jets pump
1 and all other components.
8.0 Spa Fill Up Procedure
For best results, read each step in its entirety before proceeding with this
procedure. Make sure all drains are closed before you begin, page 14.
1. Prepare The Spa For Filling
• Clear all debris from the spa. (Although the spa shell has been
polished at the factory, you may want to treat it with a specially
formulated spa cleaner.) Consult your authorized Jacuzzi dealer for
additional information prior to lling spa.
• Remove both ProClarity™ and ProClear™ Plus skimmer, polishing
lter lids and lters as illustrated in Section 13.1 (page 51).
2. Fill Spa
• Place the end of your garden hose into empty skimming lter tting
(on your left) as you stand next to the spa. Fill spa half way, then
place the garden hose into the opposite lter tting (on your right)
while adding the remaining ll water.
CAUTION: TO DECREASE BUILD UP ON COMPONENTS AND
MINIMIZE ACRYLIC DAMAGE.
Never ll with water from a water softener. If your water is
extremely “hard,” it is preferable to ll half-way with hard water and
the rest of the way with softened water. Water that is too soft can
be corrosive to metal components.
