Assembly Instructions Cont’d
8 - Connect Heater Connection Under Bench
1. Locate the power supply on the left side wall.
2. The outlets in the power supply are numbered. Match the six (6) numbered black IEC plugs with the numbered
outlets and plug them in. Make sure they are well seated.
3. Plug the cable with the Blue/Red/Green wires and molex connector into the receptacle in the power supply.
4. Locate the wood power supply guard.
5. Place it over the power supply and screw it in place.
