8
www.jacuzzi.com
Assembly Instructions Cont’d
1. Place the left side wall in the slot in
the floor positioned as in the drawing
below.
2. When the wall is in place, make sure
the metal rod is positioned in the
metal nut in the floor.
3. Screw the metal bolt from the top of
the panel into the metal nut in the
floor using your hand to twist the
metal rod.
4. Repeat this step installing the Right
Side Wall.
4 - Connecting Side Walls
Left Side Wall Installed
Right Side Wall Installed
If the panels still seem too tight to come down all the way, try backing off the
bracket screws by one half turn with a Phillips head screwdriver.
Jacuzzi
®
Saunas JS-1i and JS-2i
