Jacuzzi Magnum - Parts Diagram for Magnum, Magmun Plus, & Magnum Force Models

PARTS DIAGRAM FOR MAGNUM, MAGMUN PLUS, & MAGNUM FORCE MODELS
FIG. NO. PART NO. DESCRIPTION
1
2
3
4
4a
5
5a
6
7
9
9a
9b
10
11
*12
13
14
15
16
17
18
19
20
21
22
23
24
25
42-2828-06-R
39-2579-02-R
47-0358-03-R
47-0434-01
16-1097-04-R
43-3036-01-R
03-0856-02-R
03-2009-04-R
47-0112-00-R
31-1609-06-R
12-1069-02-R
12-1124-05-R
12-1126-03-R
14-4231-07-R
47-0232-54-R
14-4206-08-R
06-0157-05-R
06-0165-05-R
06-0167-03-R
10-1462-07-R
05-3800-01-R
05-3818-01-R
05-3819-00-R
05-3820-07-R
05-3854-06-R
05-3855-05-R
10-1502-09
47-0364-47-R
02-1392-02-R
02-1366-04-R
02-1393-01-R
02-1368-02-R
14-1293-24-R
42-2886-05-R
42-2867-08-R
42-3555-03
24-0138-07
Cover retainer
Strainer cover 7/88
O-Ring – Units after 7/89
O-Ring 5-5/8 x 6-1/8 x ¼ - Units prior 7/89
Strainer basket with Flapper
Flapper
Magnum body strainer 2” with plugs
Magnum Force body
Plug O-Ring (2req’d)
¼” plug with 47011200 O-Ring
Base motor support assembly 2/88
Motor support
Motor base
Dowel pin ¼ x 1-¼ SS 4/89
Square ring
Hex wash. hd. A8 – 16 x 1
¼
SS (2 req’d)
Diffuser, ½ HP full rate & ¾ HP uprate
Diffuser, 5-
¼
fit. 1-½ – 3 HP full rate & 2 HP uprate
Diffuser, 4.875 fit. ¾ - 1 HP full rate 1 – 1-½ HP uprate
Eye seal
Impeller, ½ HP full & ¾ HP uprate 4-3/16” Dia.
2 HP, full rate 5-3/16” Dia.
1-½ HP full rate 2 HP uprate 5-1/8” Dia.
3 HP full rate 5-1/8” Dia.
1 HP full rate 1-½” HP uprate 4-¾” Dia.
¾ HP full rate 1 HP uprate 4-¾” Dia.
Shaft seal (replaces 10139004)
O-Ring
Seal housing, 5-
¼
fit. 1-½ – 3 HP full rate, 2 HP update
Seal housing, 4-9/16 fit. ½ HP full rate, ¾ HP uprate
Seal housing, 4-7/8 fit. ¾ - 1 HP full rate 1-½ HP uprate
Motor housing bracket
PL hex capscrew 3/8 – 16 x 7/8 (4 req’d)
Pump mounting nut 2/88
Mounting nut rachet
Motor, see chart pg. 57 for selection
Motor support kit GE to Century
Case/Base assembly
NOTE:
3 each required for diffuser 06-0165-05-R. 5 each required for diffuser 06-0167-03-R
