Jacuzzi Magnum - Parts Diagram for Lr, Lr9 Lrx, Lrt, Lr3, Lr6, Lr25, Lvl

PARTS DIAGRAM FOR LR, LR9 LRX, LRT, LR3, LR6, LR25, LVL
FIG. NO. PART NO. DESCRIPTION
1
2
3
4
5
5a
6
7
8
9
10
11
12
13
15
16
17
42-1678-09-R
39-0753-04-R
47-0352-41-R
16-0240-02-R
16-1052-15-R
16-0307-02-R
03-1957-24-R
16-0985-01-R
47-0258-53-R
10-1462-07-R
05-3760-09-R
05-3759-02-R
05-3821-06-R
05-3853-07-R
10-0002-06-R
02-1388-08-R
14-3970-04-R
14-4238-00-R
14-3971-03-R
14-4239-09-R
31-1609-06-R
23-4856-00-R
23-4718-08-R
23-4863-01-R
12-1109-04-R
Strainer nut
Strainer cover
O-Ring
Basket LR
LVL Strainer Basket
Strainer case assy. With plugs LR
Case assy. With 1 plug and O-Ring LVL
Strainer case assy. 9.00 disch.
Square ring 6 x 1/8 x 1/8
Seal ring
Impeller for 5LVL, 5LR, ½ HP, 3.45D, #9838
Impeller for 7LVL, 7LR, ¾ HP, 3.73D, #9838
Impeller for 1LVL, 1LR, 1HP, 4.0D, #9838
Impeller for 15LVL, 16LR, 1½ HP, 4.22D, #1135D
Mechanical seal
Bracket
PL. Hex 10 – 24 x 1¼ (6 req’d) LR
SS Hex 10 – 24 x 1¼ (6 req’d) LRDV & LVL
PL. Hex nut 10 – 24 (6 req’d) LR
SS Hex nut 10 – 24 (6 req’d) LRDV & LVL
Plug with 47-0112-00 O-Ring
Cord with plug 6ft. F/LRX, LR6, 6ft. with 3 prong grounded plug
Cord with plug 25 ft. F/LR25
Cord with plug #12-3 115v 3ft. all LR3, twist-lock plu
LVL/LTVL with 8587-4105 motor support
Motor
