Jacuzzi Magnum - Parts for Models Rc, Urc, Rtc, Urtc

PARTS FOR MODELS RC, URC, RTC, URTC
FIG. NO. PART NO. DESCRIPTION
1
3
4
5
6
7
8
9
10
11
12
13
14
15
16
03-2001-02-R
31-1609-06-R
47-0466-02-R
14-4244-02-R
12-1036-02-R
47-0462-06-R
14-4206-08-R
06-0157-05-R
06-0163-07-R
06-0164-06-R
06-0166-04-R
10-1462-07-R
10-1463-14-R
10-1464-13-R
05-3806-05-R
05-3800-01-R
05-3801-00-R
05-3802-09-R
05-3803-08-R
05-3805-06-R
05-3852-08-R
10-1389-07-R
02-1389-07-R
02-1351-01-R
02-1610-08-R
14-1266-35-R
14-1293-24-R
2” Case/Flange Assy.
Drain plug with 47-0112-00 O-Ring
Square ring
Base fastener kit 2” 4/90
Base assembly (with Fastn. Kit #5)
Square ring
Diffuser, bolt 8-16 x 1 ¼ SS (2 Req’d)
Diffuser, ½-1 HP full rate & 1½ HP uprate
Diffuser, 1½ -2 HP full rate & 2 HP uprate
Diffuser, 3 HP full rate
Diffuser, “New” 2HP full rate
Eye seal, ½-1 HP full rate & 1½ HP uprate
Eye seal, 1½-2 HP full rate & 2 HP uprate
Eye seal, 3 HP full rate eff.
Impeller, 5URC UR. 3-5/8” dia.
Impeller, ½ HP full rate & ¾ HP uprate 4-3/16” dia.
Impeller, ¾ HP full rate & 1 HP uprate 4-1/16” dia.
Impeller, 1 HP full rate & 1½ HP uprate 4-25/64” dia.
Impeller, 1½ HP full rate & 2 HP uprate 4-9/16” dia.
Impeller, 3 HP full rate 4¾” dia.
Impeller “new” 2 HP full rate 5” dia.
Shaft seal
Bracket, 4½” fit ½ - 1 HP full rate & 1½ HP uprate
Bracket,4-29/32” fit 1½ - 3 HP full rate & 2 HP uprate
Bracket, 5-5/32” fit “new” 2 HP full rate
Bracket bolt ¼ - 20 x ¾ SS (8 req’d)
Motor bolt 3/8-16 x 7/8 SS (4 req’d)
Motor
