Jacuzzi Magnum User Manual

PARTS DIAGRAM FOR CYGNET
FIG. NO. PART NO. DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
42-1678-09-R
39-0753-04-R
47-0352-41-R
16-1052-15-R
16-1105-04-R
47-0112-00-R
31-1609-06-R
14-4231-07-R
14-1301-02-R
14-0722-01-R
14-0727-06-R
14-4206-08-R
06-0150-07-R
10-1462-07-R
05-3936-08-R
05-3937-07-R
05-3939-05-R
05-3940-02-R
10-0002-06
47-0361-48-R
11-1520-00-R
90-1069-15-R
90-1069-23-R
90-1069-31-R
90-1069-49-R
12-1135-02-R
Strainer RingLok
Strainer cover
Strainer O-Ring 4-7/8 ID x 3/16 THK
Strainer Basket
Case with 2” plugs
Plug O-Ring (2)
Plug with O-Ring (2)
Base dowel pin
SS Bolt 3/8-16x2 - ½ (4)
SS Lock washer – 3/8 (4)
SS Nut 3/8-16 (4)
Diffuser screws 8 – 16 x 1¼” (2)
Diffuser
Eye seal
IMP ¾ HP
IMP 1 HP
IMP 1½ HP
IMP 2 HP
Mechanical seal
O-Ring 6” ID x 3/16 THK
Seal plate
Motor ¾ HP
Motor 1 HP
Motor 1½ HP
Motor 2 HP
Base assy.

Jacuzzi Magnum Specifications

General

Horsepower	1.5 HP
Voltage	115/230V
Flow Rate	90 GPM
Inlet/Outlet Size	2 inches
Material	Plastic
Port Size	2 inches
Phase	Single
