Jadis Orchestra User Manual

Unpacking and checking
The Orchestra integrated amplifier has been packed in a box that has
been specially designed for it. Do not throw away this box as it will be
needed for re-packing the unit when it has to be returned to the factory for
maintenance or upgrading. Please note that the warranty will be considered
as cancelled if the unit has been dispatched incorrectly packed.
The boxes should contain: The module block of the orchestra, its
tubes, the mains power cable and one 6-sided spanner which is used to
remove the covers of the units to allow the tubes to be changed when
necessary.

Jadis Orchestra Specifications

General

Type	Integrated Amplifier
Signal to Noise Ratio	90dB
Tube Complement	4 x EL34, 3 x ECC83
Weight	20 kg
Frequency Response	20Hz - 20kHz
Input Impedance	100kΩ
Output Power	40 Watts per channel
Outputs	Speakers
Output Impedance	4 and 8 Ohms
Inputs	4 x RCA (Line Level)
