ASSEMBLY OF THE STEERING SERVO AND STEERING SERVO MOUNT

ASSEMBLY OF THE STEERING SERVO AND STEERING ROD

ASSEMBLY OF THE STEERING SERVO ONTO CHASSIS

Step 1

Step 2

94002

3x8mm

Hex Screw

.....x5

*Approx. 28mm

*ｬ28mm

1:1

37650

30400

(3x46mm)

Step 1

Step 2

3x8mm

37100

3x6.4x2mm

Plastic Bushing

.....x1

37360

37100

3x10mm

94019

3x10mm

Flat Head Hex Screw

.....x2

94040

3x8mm Washer

.....x4

3x8mm

* Use the screw

provided with

your servo .

30661

S J F

Sanwa/Airtronics

Futaba

HiTech

* Choose the right servo horn adapter for your servo.

40946
