ASSEMBLY OF THE WHEEL BEAD LOCKS

ASSEMBLY OF THE TIRE ONTO FRONT KNUCKLE AND REAR HUB

ASSEMBLY OF THE BODY

18

94057

2x6mm

Hex Screw

.....x44

40865

40865

4mm Nylon Nut

.....x4

Cut Out

40937

*A ire and wheel.ssembled t

Step 1

Step 2

Cut Out

2x6mm

40951 GRAY

40939 RED

40940 BLUE

*Cut out the body as picture shown.

*Make four tires that are the same.

SCRT DECAL SHEET 40938

40949 TIRES

40952 SPONGE
