ASSEMBLY OF THE TRANSPONDER

ASSEMBLY OF THE TRANSPONDER

CUT THE RADIO CASE

(ONLY IF YOU HAVE PERSONAL TRANSPONDER)

Step 1

Step 2

Step 3

Step 1

Step 2

Personal trasponder (Not Included)

*Bend the cut part as picture shown.

3x12mm

3x8mm

94002

3x8mm

Hex Screw

.....x1

94004

3x12mm

Hex Screw

.....x2

94001

3x5mm

Hex Screw

.....x2

3x5mm

21

Knife

*Connect transponder wire

to channel 3 on receiver.
