ASSEMBLY OF THE BATTERY CASE ONTO CHASSIS

BATTERY INSTALL

16

47

BATTERY INSTALL

94019

3x10mm

Flat Head Hex Screw

.....x4

3x10mm

3x10mm

Battery(Not Included)
