machine and arbor parts lists
13
item description part # qty
1 MOTOR ASSEMBLY, 120V 04600R 1
MOTOR ASSEMBLY, 220V 04602R
2 PIPE HANDLE 0010224 1
3 CHIP GUARD ASSEMBLY 0151570 1
4 ARBOR ASSEMBLY 0151441 1
5 DRILL FRAME 04700R 1
6 1/4" ID X 5-1/4" TUBING UH6005 1
7 QUICK ELBOW COUPLER 0070034-N 1
8 QUICK PANEL BARB COUPLER 0151271 1
9 1/2" LOCK WASHER UH2530 1
10 QUICK COUPLING SPACER 0151309 1
11 M6 X 20 HHCS UH0636 4
12 1/4" LOCK WASHER UH2402 4
13 PINION GEAR U18000 1
14 NEEDLE BEARING UH3132 2
15 THRUST WASHER 0151205 2
16 WOODRUFF KEY 0010142 1
17 PINION HUB SHAFT 0151193U 1
18 SPOKE HANDLE 0151333 3
19 M3.5 X 10 CRPHMS-ETLW UH0323 8
20 COVER PLATE ASSEMBLY 0151305 1
21 MAGNET ASSEMBLY, 120V, 220V 0151180 1
22 SAFETY STRAP LINK U11004 1
23 3/16 " ID TUBE A=5", B=10" UH6011 1
24 SPIRAL KEY RING UH8022 1
25 6-32 X 1-1/8 CRFHMS UH1035 2
26 COOLANT VALVE KIT 0151170 1
27 CONTROL PANEL ASSYEMBLY, 120V 0151036 1
CONTROL PANEL ASSYEMBLY, 220V 0151037
28 COOLANT BOTTLE ASSEMBLY 0151289 1
COOLANT BOTTLE 0151163 1
COOLANT CAP 0151165 1
RUBBER WASHER 0151169 1
COOLANT STRAINER 0151174 1
29 M6 X 25 SHCS UH0648 1
30 BLACK GEAR SHAFT END CAP 0151195 1
31 SLIDE COVER PLATE 0151113 1
32 M5 X 12 CRFHMS UH0516 2
33 CORD CASE 0151451 1
34 M3 X 12 CRFHMS UH0316 2
35 MOTOR CORD ASSEMBLY 0151448 1
36 MOTOR COVER 0151111 1
37 M5 X 10 BHSCS UH0506 4
38 PIPE HANDLE ADAPTER 0010225 1
39 6-32 NUT UH4715 2
item description part # qty
1 INTERNAL RETAINING RING UH4119 1
2 STEEL WASHER UH2606 1
3 RUBBER WASHER UH2604 1
4 ARBOR PISTON 0151435 1
5 SPRING 0151431 1
6 ARBOR PLUNGER 0151433 1
7 3/8-24 X 5/16" FPSSS UH1474 2
8 ARBOR BODY 0151437 1
9 3/8-24 X 5/16" CPSSS UH1472 1
10 1/4-20 X 1" BHSCS UH1432 1
11 PISTON SPACER 0151512 1
12 SPIRALOC RETAINING RING UH4044 2
13 O-RING UH6350 2
14 COOLANT INDUCER U22002 1
15 M6 X 16 BHSCS UH0616 2
16 1/4" LOCK WASHER UH2402 4
17 BRASS BARB FITTING UH6100 1
18 RETAINER PLATE U21002 1
19 ARBOR SLEEVE 0151439 1
20 INTERNAL RETAINING RING UH4153 1
21 THRUST WASHER 0151207 1
22 NEEDLE BEARING UH3208 1
23 GREASE FITTING UH6600 1
24 M6 X 20 HHCS UH0636 2
25 ARBOR BEARING BRKT. ASSY. 0151015 1
ARBOR PARTS LIST
MACHINE PARTS LIST
