14
Appendix 1: Specifications
Inputs & Outputs
Description Type Pin Outs Function
DMX 512 5 pin Female AXR 1
2
3
4, 5
Shield
Data –
Data +
Unused
Ethernet
(100BaseT)
RJ-45 1
2
3
4, 5
6
7, 8
Transmit +
Transmit –
Receive +
Unused
Receive –
Unused
USB (2 x) Type A 1
2
3
4
Vcc
Data –
Data +
Ground
Power 12V 5.5mm / 2.1mm
DC Power
Tip
Sleeve
+
-
General Specs
Description Value
Size 520mm wide x 300mm deep x 70mm high
Weight 4kg not including power supply
VESA Mount 100x100mm
CPU 400MHz ARM7
DRAM 128MB
FLASH 256MB
Operating System Linux
Number of Scene/Chase
Locations
92
Total number of Steps per
Chase
100+
Total number of Cues in the
Cuelist
100+
