2. Getting started
Setting up the console
Power
Connect the Stage CL’s external power supply unit to any mains supply between
100 and 240VAC. Connect the power supply’s DC connector to the Stage CL.
Feed the cable into the slot in the cable restraint.
DMX Output
The Stage CL can output one universe (512 channels) from its DMX output. Use a
5 pin DMX cable to connect the console to your lights.
Ethernet
The Stage CL supports Artnet via the Ethernet (RJ45) connector. Turn Artnet on
via the Setup menu - refer to the full user manual for more details.
USB
You can connect a USB memory stick to the console to save copies of your show
files.
