J&W JW-A880GMT-EXTREME User Manual

- 31 -
AMD Series User's Manual
4.5.8 JUSTw00t! Setting(OverClock Settings)
BIOS SETUP UTILITY
Main Advanced Boot Security Power JUSTw00T! Exit
OverClock Settings To Enabled/Disable
Onboard PCIE LAN BOOTR
←
Select Screen
↑↓
Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
►
AMD Overclocking Configuration
►
DRAM Timing ConFiguration
►
Memory Configuration
Memory CLK :N/A,667MHZ
CAS Latency(Tcl) :N/A,9 CLK
RAS/CAS Delay(Trcd) :N/A,9 CLK
Row Precharge Time(Trp) :N/A,9 CLK
Min Active RAS(Tras) :N/A,24 CLK
RAS/RAS Delay(trrd) :N/A,4 CLK
Row Cycle (Trc) :N/A,33 CLK
Dimm Voltage Control [AUTO]
Dram Voltage :1.592 V
CPU Voltage Control [Auto]
Vcore :1.328V
K10 CPUNB Voltage Control [AUTO]
NB2 Voltage Control [AUTO]
NB Voltage :1.168V
SB Voltage control [AUTO]
SB Voltage :1.256V
HT Voltage Control [Auto]
Colorful Netlive Control [Disabled]
Lan Controller [Enabled]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
►
Memory Conguration
Click <Enter> key to enter its submenu.
BIOS SETUP UTILITY
JUSTw00T!
Memory Configuration Enable Bank Memory
Interleaving
←
Select Screen
↑↓
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Bank Interleavin
Channel Inter leaving
Enable Clock to All DIMMs
MemClk Tristate C3/ATLVID
Memory Hole Remapping
DCT Unganged Mode
Power Down Enable
page smashing
[Disabled]
[Disabled]
[Disabled]
[Disabled]
[Enabled]
[Auto]
[Disabled]
[Disabled]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
