- 26 -
JW-H61M-L3 User's Manual
Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc.
Chipset
SB Chipset Configuration
Onboard LAN Controller
Onboard LAN Controller
Audio Configuration
Azalia HD Audio
USB Configuration
USB Controller
SATA Control
[Enabled]
[Enabled]
[Enabled]
Enabled/Disabled the PCI
Exp r e s s Po r ts i n th e
Chipset.
→ ←
: Select Screen
↑↓
:
Select Item
Enter: Select

+/-: Change Opt.
F1: General Help
F7: Previous Values
F8: Fail-Safe Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
Version 2.11.1210. (C)Copyright 2011 American Megatrends, Inc.
• Onboard Lan Controller
Setting lan controller switch, optional for Disabled
Enabled.
• Azalia HD Audio
Setting Azalia hd audio functions
optional for Disabled
Enabled.
• USB

Controller
Setting USB controller switch, optional for Disabled
Enabled
.
SATA Controller
Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc.
Chipset
SATA Controller
SATA Mode
Serial-ATA Controller 0
Serial-ATA Controller 1
SATA Port1
SATA Port2
SATA Port3
SATA Port4
[IDE Mode]
[Compatible]
[Enhanced]
Hitachi HCP725 (320.
Not Present
Not Present
Not Present
IDE Mode.
Disbaled
→ ←
: Select Screen
↑↓
:
Select Item
Enter: Select

+/-: Change Opt.
F1: General Help
F7: Previous Values
F8: Fail-Safe Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
Version 2.11.1210. (C)Copyright 2011 American Megatrends, Inc.
SB Devices Control
Press < ESC> key to return to the Chipset menu
• DVMT Mode Select
Select DVMT Mode used by Internal Graphics Device.
• DVMT/FIXED Memory
Select DVMT/FIXED Mode Memory size used by Internal Graphics Device.
