J&W JW-H61M-L3 User Manual

- 27 -
JW-H61M-L3 User's Manual
Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc.
Chipset
Intel ME Subsystem Configuration
ME Version
ME Subsystem
ME Temporary Disable
End of Post Message
7.0.4.1197
[Enabled]
[Diablsed]
[Enabled]
ME Subsystem Help
→ ←
: Select Screen
↑↓
:
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F7: Previous Values
F8: Fail-Safe Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
Version 2.11.1210. (C)Copyright 2011 American Megatrends, Inc.
►
ME Subsystem
ME Subsystem

optional for
Disbaled、Enabled。
ME Temporary Disable

optional for
Disbaled、Enabled。
End of Post Message

optional for
Disbaled、Enabled。

Press < ESC> key to return to the Chipset menu
►
Serial Port Control
Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc.
Chipset
Serial Port Control
Super IO Chip
►
Serial Port 0 Configuration
NCT5577D
Set Parameters of Serial
Port 0 (COMA)
→ ←
: Select Screen
...
ESC: Exit
Version 2.11.1210. (C)Copyright 2011 American Megatrends, Inc.
►
Serial Port 0 Confguration

Press < ESC> key to return to the Chipset menu
• SATA Port 1/2/3/4
This item is a lists of the system detects the current SATA equipment and device type.
• Serial-ATA Controler 0/1
Setting Serial-ATA 0 or 1 controler, optional for Disabled, Enhanced, Compatible.
• SATA Mode
Setting Serial-ATA Mode
，
optional for Disbaled
、
IDE Mode
、
AHCI Mode
.

J&W JW-H61M-L3 Specifications

General

Brand	J&W
Model	JW-H61M-L3
Category	Motherboard
Language	English
