S1 DIP #6 ON
When OFF a separate heater is used for the pool and spa. When ON the pool
and spa share the same heater.
S1 DIP #7 ON
Change air sensor to solar sensor - Air temperature no longer displayed.
Adjustable Freeze Kit must be added for freeze protection.
S1 DIP #8 ON - Heat Pump Instead of Gas Heater
Turn this switch ON if you have installed a heat pump instead of a gas heater.
After thermostat setting has been reached, heater will remain OFF for 5
minutes.
S2 DIP #1 ON - Heat Pump Priority
This switch is used for conguring solar priority or heat pump priority. Set this
switch to ON if Heat Pump Priority will be used. Set this switch to OFF if Solar
Priority is to be used.
AquaLink RS Conversion Kit available accessories
All Button Indoor Controller
OneTouch Indoor Controller
Wireless Remote (AQWHR18 dedicated water resistant)
4 Button Spa-Side (7443, 8050, 7444)
10 Button Spa-Side (7227, 7887, 7888, 7940)
6.2 DIP Switch Settings
S1 DIP
Switch #
OFF ON
1
AUX1= any equipment AUX1= Pool Cleaner
2
AUX2= any equipment AUX2= Low Speed for a
two-speed filter pump.
Filter pump circuit becomes
High Speed.
3
NOT USED NOT USED
4
Heater cool down
operates.
Heater cool down disabled.
5
Normal operation Factory adjustment-
when this switch is on,
temperature delays are
eliminated and solar
temperature is displayed.
Do not leave this switch
in the ON position.
6
Separate Pool and Spa
heater.
Sharing one (1) heater for
pool and spa.
