Jandy DEV60 - Section 10. Head Loss Curves; Jandy DEV Filter Design Head Loss Curves

Page 15Diatomaceous Earth Pool Filters - DEV Series Filter
Section 10. Head Loss Curves
10.1 Jandy® DEV Filter Design Head Loss
Curves
0
2
4
6
8
10
12
14
16
18
20
22
0 30 60 90 120 150
0
1
2
3
4
5
6
7
8
9
DEV48
DEV60
Design
Head
Loss
(ft head)
Design
Pressure
Drop
(psi)
Flow Rate (gpm)
