Jandy JRT2500R User Manual

Page 27
ENGLISH
Jandy
®
JRT Series Heat Pumps
|
Installation and Operation Manual
1 Fan Grille All R0933900
2 Fan Motor All R0934000
3 Fan Blade All R0934100
4 Fan Top All R0934200
5 Evaporator Coil / Guard 2000R, 2500R R0934300
5 Evaporator Coil / Guard 3000R R0934400
6 Compressor 2000R R0934500
6 Compressor 2500R R0934600
6 Compressor 3000R R0934700
7 Base All R0934800
8 Electrical Box Cover w/ Hardware All R0934900
9 Front Panel 2000R, 2500R R0935000
9 Front Panel 3000R R0935100
10 Temperature Sensor All 7790
11 Filter Drier All R0935200
11 FilterDrier(Bi-ow) All R0935300
12 Thermal Expansion Valve 2000R, 2500R R0935400
12 Thermal Expansion Valve 3000R R0935500
13 Air Temperature Sensor All R0935600
14 High Pressure Switch All R0935700
15 Low Pressure Switch All R0935800
16 Water Pressure Switch All R0935900
17 User Interface All R0591900
18 Interface Cover All R0592000
19 Reversing Valve (optional) All R0936000
20 Transformer All R0936100
21 Power Interface PCB All R3009200
22 Fan Capacitor All R0936300
23 Run Capacitor (1 phase) All R0936200
24 Contactor (1 phase) All (1 Phase) R0936400
25* Anchor Bracket Set All R0936600
26 Universal Union, Butress Set All R0472700
27* Schrader Valves (2-pack) All R0937100
28* External Fastener Kit All R0937300
29* Compressor Blanket All R0951700
* Not Shown
9.1 Ordering Information
To order or purchase parts for the JRT models of heat pumps, contact your nearest Jandy dealer or distributor. See
the Jandy web site at www.Jandy.com for the nearest service center. If they cannot supply you with what you need,
contact Jandy customer support department, telephone (800) 822-7933.
Section 9. Replacement Parts
9.2 Jandy JRT Heat Pumps Parts List
Key
No. Description Model No.
Order
Part No.
