Janome 9102D - How to Turn the Handwheel; Opening and Closing the Side Cover; Opening and Closing the Looper Cover

www.toews.com
12
How to Turn the Handwheel
Always turn the handwheel toward you (Counter-
clockwise).
1 Handwheel
Opening and Closing the Side Cover
To open:
Push the side cover to the left.
To close:
Push the side cover to the right.
1
Side cover
Opening and Closing the Looper Cover
To open: A
While pushing with the thumb to the right as far as it
will go, pull the looper cover toward you.
To close: B
Lift the looper cover and push it against the machine.
The looper cover snaps into its position
automatically.
1
Looper cover
NOTE:
Always close both side cover and looper cover when
the machine is in use.
1
1
1
A
B
Janome 9102D Instruction Manual
