Janome DC1050 - Circuit Board-A

24
CiRCuit boaRd-a(2)
setting tHe CiRCuit boaRd a
RePlaCing tHe eleCtRoniC ComPonents
afteR install tHe CiRCuit boaRd a, seleCt tHe aPPRoPRiate setting of tHe CiRCuit boaRd a.
1. TURN THE POWER SWITCH ON WHILE SIMULTANEOUSLY PRESSING LEFT CURSOR BUTTON
“ ” AND THE RIGHT CURSOR
“ ” BUTTON.
2. AFTER THE BUZZER SOUNDS, PRESS THE LCOKING STITCH BUTTON
q
WITHIN 2.5 SECONDS.
THE LCD SHOULD DISPLAYS “S”.
IF NOT, PRESS THE LOCKING STITCH BUTTON TO SELECT “S”.
3. PRESS THE START/STOP BUTTON TO DETERMINE THE SETTING.
A LONG BUZZER SOUNDS WHEN THE SETTING IS CORRECTLY FINISHED.
4. TURN THE POWER SWITCH OFF.
q
w
