13
q
z
x
w
e
r
t
y
c
v
n
• Winding the bobbin
NOTE:
•Setthespeedcontrolslideratitsfastestposition
for bobbin winding.
z Draw the thread from the spool.
Guide the thread around the Bobbin winding
tension disk.
q Bobbin winding tension disk
x Put the bobbin on the bobbin winder spindle.
w Bobbin
e Bobbin winder spindle
c Pass the thread to the bobbin.
Hold the thread with both hands and wind it around
the bobbin clockwise several times.
v Insert the thread into one of the slits t of the flange
plate r and pull the thread to cut.
r Flange plate
t Slit
b Push the bobbin to the right.
The bobbin mark y appears on the LCD display.
y Bobbin mark
b
m
n Start the machine. When the bobbin is fully wound, it
will stop automatically. Stop the machine and return
the bobbin winder to its original position by moving the
spindle to the left.
m Insert the thread into one of the slits of the flange
plate and pull the thread to cut.
