operation instructions
and blade/pilot pin information
Model VC
page 9 of 12
JARVIS
6222009::.
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-- 4926
UNITED STATES OF AMERICA E--MAIL. jarvis.products.corp@snet.net
TEL. 860--347--7271 FAX. 860--347--6978 WWW.jarvisproducts.com
®
6.4 A gentle motion with a downward pressure will
cut the bird properly. Forcing the blade will
leave all or part of the rosebud in the bird.
Do
not
force the blade or stab the bird with the
blade. Do not
let go of the trigger after fully de-
pressing it. The blade will turn only a few revo-
lutions and will shut off automatically (it will
not cut the intestines). The vacuum will remain
sucking as long as the trigger is h eld in the fully
depressed position.
6.5 The blade must always be angled toward the
center of the bird. If the blade is directed toward
either side, it will leave solid muscle attached to
the vent and this material cannot be broken loose
by hand.
6.6 While still holding the trigger, pull the blade
slowly out of the bird. The vacuum will hold the
anus and the fecal material long enough for the
operator to either grab the vent and move it away
from the hole or to move the vent away from the
hole with the gun.
6.7 Release the trigger. The vacuum will shutoff
and release the vent into the operators hand so
that it can be pulled out of the carcass and laid
gently over the side of the carcass or it will re-
lease the vent over the side of the carcass if the
vacuum pulls the vent completely out of the car-
cass.
6.8 After releasing the vent, the operator must aim
the blade at the trough before reaching the next
bird. Depress the water flush lever to flush out
all materials from the blade before attempting to
cut another bird. Do not
flush waste material on
the birds. The water will not flush out the blade
unless the vacuum trigger is in the rest position.
When both vacuum and water triggers are acti-
vated, all water will be sucked up the vacuum
tube sending all waste material to the collector
tank.
6.9 When a bird has fecal material on the outside of
the carcass, it can be washed off with the vent
gun before cutting the bird. Be sure that the
blade has been sufficiently flushed into the
trough before attempting to wash off any bird.
Do not
attempt to wash the bird after cutting into
the carcass.
BLADE INFORMATION (inches)
PART NO. DIAMETER LENGTH
3332001 7/8 15/8
3332002 3/4 15/8
3332003 1 2
3332004 11/4 2
3332005 11/2 2
3332006 7/8 21/2
3332008 11/8 31/2
3332009 11/4 31/2
3332010 13/8 31/2
3332011 11/2 31/2
3332015 11/8 2
3332016 13/8 2
3332026 13/4 23/4
PILOT PIN INFORMATION (inches)
PART NO. DIAMETER LENGTH
1327038 3/8 2
1327040 1/2 21/2
1327041 5/16 2
1327052 1/2 31/4
1327053 3/8 23/4
1327054 3/8 21/2
1327057 3/8 33/4
