Jasco ZigBee ZB3001 (45857) User Manual

KeyFeatures
 TurnON/OFForDIMlightingmanuallyorremotelyviatheZigBeecontroller
 CanbeIncludedinmultipleGroupsandScenes

MaybeusedinsinglepoleinstallationorwithuptotwoJascoauxiliaryswitchesin2‐way,3‐
wayor4‐waywiringconfigurations
 WorkswithDimmableCFL/LEDbulbsforimprovedenergyefficiency
 InterchangeablePaddleswitch:White&lightalmondpaddleinpackage
 OvertheAirupdates –OncejoinedtoyourZigBeenetwork,thedevicecantransparentlyreceive
updatesthroughyourZigBeegateway
 EnergyMonitoring–Thedevicecanreportwattage(W)andkilowatthours(kWh).Energyusage
ismonitoredthroughtheZigBeeControllerInterface
 Usesastandard,decora‐sizewallplateforsingleganginstallations(wallplatenotincluded)
 BlueLEDindicatesswitchlocationinadarkroom(LEDcanbeenabled/disabledmanually)
 LEDStatusIndicator–Indicatesdevicescanningduringpairingprocess
 ZigBeeHA1.2Certifiedforsimplepairingandintegratedhomeautomation
 ScrewTerminalinstallation;requireswiringconnectionsforLine(Hot),Load,Neutral,and
Ground.Travelerwirerequiredformultipole installation
To change color of the switch
1. LifttheAirGaptabatthebaseofthecover.
2. Pushsidetabsinononesideandthentheothertoreleasecover.Liftthecoverupandoff.
3.
Simplyputthenewcoverontotheswitchbyinsertingtheairgapandsidetabsandsnappingsecurely
intoplace.
Installation
Thisswitchmaybeusedinnewinstallationsortoreplaceanexistingwallswitch.Itmaybeusedbyitself
for2‐waycontrol(oneswitch&oneload),withoneJascoAuxiliarySwitchfor3‐waycontrol(two
switches&oneload)orwithtwoJascoAuxiliaryswitchesfor4‐waycontrol(threeswitches&oneload).
Whenusedbyitselffor2‐waycontrol,pleasemakesurethatthescrewterminalforthetravelerwireis
insulated(DoNotRemovethetapeovertheterminalifyouarenotusing thetravelerconnection)
WARNING‐SHOCKHAZARD
TurnOFFthepowertothebranchcircuitfortheswitchand
lightingfixtureattheservicepanel.Allwiringconnectionsmust
bemadewiththePOWEROFFtoavoidpersonalinjuryand/or
damagetotheswitch.

Jasco ZigBee ZB3001 (45857) Specifications

General

Brand	Jasco
Model	ZigBee ZB3001 (45857)
Category	Switch
Language	English
