Jasic ARC140 - Page 16

OC
10
1
2
3
4
5
6
7
1
3
2
1
2
3
4
5
No. Part name Function
“+”
terminal
output
To connect the welding output cable.
Current
control knob
To adjust the output current value.
“-”
terminal
output
To connect the welding output cable.
6
Digital meter To display the welding current.
1
2
3
No. Part name Function
Power
switch
To control the ON/OFF of the input
power of the machine.
Cable For power supply input.
Cooling fan
For heat dissipation through forced
air cooling.
3.4 Panel functions of ARC200 Z276 ( )
7
Figure 3-6: Back panel of Z276
Figure 3-5: Front panel of Z276
Arc force
control knob
To adjust the arc force current value.
Overheating
indicator
To indicate the temperature inside the machine
is too high and the machine is under overheating
protection status when it illuminates.
Overcurrent
indicator
To indicate the machine is under overcurrent
protection status when it illuminates.
3. OPERATION
