Jasic Cut 100 - Page 4

4
Item No Part Number Descripon Pack Qty
1 02001 P150LT Torch Head (hand) 1
1a 09706 P150LT Handle c/w Switch 1
1b C1398 'O' Ring - Torch Head 5
1c C1017 Front Insulator - Vespel 1
3 C1378 Diuser 1
4 C1376 Electrode Hafnium 5
5 C1377 Swirl Ring Vespel 1
6 C1371 Cung Tip 1.1mm 60A 10
6 C1372 Cung Tip 1.35mm 90A 10
6 WB300128 Gouging Tip 2.4mm 100A 10
8 C1018 Extended Diuser 1
8a C1517 Extended Electrode 5
9 C1369 Extended Tip - Max 50A 10
10 C1001 Extended Tip 1.35 - 90A 10
11 C1389 Nozzle Retaining Cap 1
12 C1393 Contact Nozzle Retaining Cap 1
13 C1007 Spring Holder Protecon Nut 1
14 C1008 Stand O Spring (for C1007) 5
15 C1009 Gouging Spacer (use with item 12) 1
16 C1010 Spacer for Contact Cung (use with items 6, 12 & 22) 1
17 C1406 Gouging Spacer (use with item 11) 1
19 C1014 Shield Cup - Max 50A 1
20 C1015 Spacer for Contact Cung 1
21 C1020 Spacer for Extended Tips (90A and above) 1
22 C1016 Locking Nut 1
23 C1386 Stand O Spring 5
24 C1408 Double Pointed Spacer 1
25 C1409 Crown Spacer 1
27 C1509 Extractor for Swirl Ring 1
28 C3045012 Wrench for Electrode 1
Please Note: Only use the above conguraon for the Jasic Cut 100 model
Jasic Cut 100 Plasma with P150LT 6m Hand Torch
Wilkinson Star Technical
