Jasic Cut 160 - Technical Data

Technical data
3
Tested at the environment temperature of -10
0
- 40
0
C
Product design may vary due to customer requirements.
6
MODEL
CUT 160
Rated input voltage (V)
Three phase 400V AC±15%
Rated input frequency (Hz)
50/60
Rated input capacity (KVA)
29.2
Recommended supply fuse (A)
50
Compressed air requirement
170L/Min. 6Bar
No load voltage
330V DC
Cutting current (A)
30-160
Rated output voltage (V)
144
Rated duty cycle (%)
160A @ 60%
Efficiency (%)
85
Power factor
0.99
Insulation class
F
Protection class
IP21S
Arc ignition
HF
Maximum cutting thickness (mm)
60 (Carbon steel)
Weight (kg)
55
Overall size (mm) (L×W×H) without handle
676*333*712
