13
5CraterV oltage/HotStart
ItregulatesthecratervoltageunderMIGmode,andadjuststhestarting
currentatarcinitiationinMMAandGOUGINGmodes.Notusedin
TIGmode.
6Inductance/ArcForce
It
’ susedtoadjusttheinductanceunderMIGmode,andunderMMA
andGOUGINGmodes,it ’ susedtoadjuststhearcforce.Notusedin
TIGmode.
7VoltageMeter
BeforeMIGoperation(currentflow),themeterdisplayspresetvoltage
value,beforetheothermodesoperation,themeterdisplaystheVRD
Voltage.
Duringwelding,thismeterdisplaysactualaveragevolts.
8PowerLEDThisLEDlightsupindicatesthewelderhasbeenturnedon.
9OverHeatLED
ThisLEDlightsupindicatestheweldergetsintooverheatprotection
andnooutputfortheweldertowork.
10OverCurrentLED
ThisLEDlightsupindicatestheweldergetsintoovercurrent
protectionandnooutputfortheweldertowork.
11VRDLEDIndicator
ItisgreenwhentheVRDworks.TheVRDfunctionisunsuitablefor
MIGmode.
5.1.2
5.1.2
5.1.2
5.1.2Wire
Wire
Wire
Wirefeeder
feeder
feeder
feederfront
front
front
frontpanel
panel
panel
panel
