JAUDT DKV 6008 Series User Manual


© BA_DKV_EN_Rev07-2010.DOC Page 7 von 20
3.3.1 Hand-lever (Page 5 Position 6)
Manual operation with indicator (7) for the position of the sealing plate.
Also in stock: retaining pin, sealing-off fitments, locking facilities (not illustrated).
3.3.2 Pneumatic Operation
Filtered compressed air, water-free, oiled, pressure 7 11 bar abs.
Pneumatic cylinder (11)
Pneumatic rotating actuator PDA (14) with 5/2-way solenoid valve
3.3.3 Electric servo drive (9) (illustrated with motor type 0A 8)
Standard equipment:
Three-phase positioning drive, 230 V/400 V 50 Hz, ISO F, IP65
 - 
The user must ensure that the electrical connections run via motor protection switches.
Connection to power is the sole responsibility of the user and his own qualified personnel.
The instructions from the motor manufacturer regarding start-up, maintenance and installed position must
be observed. This information can be supplied by JAUDT if necessary.
3.4 Technical Data – Rotating actuator (PDA)
With distribution with a rotating actuator PDA - the technical documentation is supplied of this operating
manual.
Standard version Rotating actuator PDA:
Make
ACG
Type
AC-A83DA
AC-A92DA
AC-A105-DA
DKV Ø
100, 150
200, 250
300, 350
3.5 Technical Data – Electric servo drive
With distribution with a electric servo drive - the technical documentation is supplied of this operating man-
ual.
Standard version Electric servo drive :
Make
DEUFRA
Type
OA-6  6 sec
OA-8  6 sec
AS-18  5 sec
DKV Ø
100, 150
200, 250
300, 350
