34
Fig. 18. Chaincase lid
6. ADJUSTING THE CLUTCH
If it is found when riding that the clutch is slipping. the fault can be generally
remedied by turning the automatic clutch adjusting the screw (in the R.H cover
opening) by 1/6 or 2/6 to the left. It is recommended to adjust the hand and
automatic declutching more accurately from time to time in the following manner:
a) Screw the hand clutch adjusting screw on the handlebars slightly thus
releasing the clutch lever.
b) Clean with petrol or paraffin any dirt from the automatic clutch cam (6) and
the clutch roller (5).
c) With your left hand take hold of the automatic clutch roller (5) and move it
towards the cam and back.
d) If there is any movement, turn the automatic clutch adjusting screw (4) to the
right, until the space between the roller (5) and cam (6) is approx. 0.1 to 0.3 mm.
