Operator’s Manual - 30 - Trailer Units - Model 3650
Dual Discharge – 8’ (96”) or 9’-2” (110”) Conveyors
On machines equipped with dual side unloading, the conveyor will unload on either side of
the machine. The conveyor is operated by using the controls on the tractor, for left and right
discharge. (The conveyor will reverse from its direction of discharge, when the remote is
moved to the opposite position).
CHAIN TIGHTENER
ASSEMBLY (1 PER
SIDE.)
DISCHARGE
CONVEYOR
ASSEMBLY
Figure 12 - Chain Tightener Assembly.
D
I
S
C
H
A
R
G
E
D
I
R
E
C
T
I
O
N
Figure 13 - Dual Discharge Conveyor Assembly.
