Rack mount Series UPS (1~3kVA) User ‘s Manual
-26-
12
Battery
Status
75%-100%
Battery
3 beeps every
10 seconds
○ ● ● ● ××● × ● ●
13 ≥100％Battery
3 beeps every
10 seconds
● ● ● ● ××● × ● ●
14
Bypass status
(shutdown)
Silent ▲ ▲ ▲ ▲ ▲ ▲ × ○ ▲ ▲
15
counter-connection for L,
N
Beeping
Every 1
minute
▲ ▲ ▲ ▲ ▲ ○ ▲ ▲ ▲ ▲
16 Low-battery alarm
Beeping
Every 0.5
seconds
×××○ ○ × ● × ● ●
17
Final 10S for
remote-shutdown
1 beep every
1.5 seconds
▲ ▲ ▲ ▲ ▲ ▲ ○ ▲ ▲ ▲
18
UPS Checking no battery
connection
Silent
▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ ○ ▲
19
Mains supply abnormal
3 beeps every
10 seconds
▲ ▲ ▲ ▲ ▲ × ▲ ▲ ▲ ▲
20
Over-load protection in
mains supply mode
Long-
Beeping
○ ○ ○ ○ ● ● × ● × ▲
21
Over-load protection in
battery supply mode
Long-
Beeping
○ ○ ○ ○ ● ×× ● ● ×
22
Low-battery protection in
battery supply mode
Long-
Beeping
××××● ×× ● ○ ×
23
Output short-circuit
Long-
Beeping
● ×××● ▲ × ● ▲ ×
24
INV Fault
Long-
Beeping
× ● ××● ▲ × ● ▲ ▲
25
DC—BUS Fault
Long-
Beeping
××● × ● ▲ × ● ▲ ▲
26
UPS over-temperature
Long-
Beeping
×××● ● ▲ × ● ▲ ▲
×：light off；○：Flashing；●：Long time light on；▲：Keep original status
