Jaycar QM1571 - Operating Environment; DC Voltage (Auto-ranging)

www.procontechnology.com.au Phone: (03) 98306288
Operating environment: -10°C to 50°C (14°F to 122°F)
at <70% relative humidity.
Storage temperature: -30°C to 60°C (-4°F to 140°F)
at <80% relative humidity
Relative humidity: 90% (0°C to 30°C); 75% (30
o
C to
40°C); 45% (40
o
C to 50°C)
Maximum altitude: Operating: 3000m
Storage: 10,000m
Pollution degree: 2
Safety: The instrument complies with IEC/EN 61010-1:2001
and IEC/EN 61010-031:2002
Power: 9V battery, NEDA 1604, IEC 6F22
Dimensions: 182 (H) x 82 (W) x55 (D) mm
Weight: Approx. 380g.
Enclosure: Double moulded, waterproof (IP67)
Accuracy is given at 18°C to 28°C (65°F to 83°F ), < 70% RH
DC Voltage (Auto-ranging)
Range Resolution Accuracy
400.0mV 0.1mV
4.000V 1mV ±0.8% of reading
40.00V 10mV
±2 digits
400.0V 100mV
1000V 1V
±1% of rdg ±2 digits
