Jaycar QM1571 - AC Voltage (Auto-ranging); DC Current (Auto-ranging)

www.procontechnology.com.au Phone: (03) 98306288
Input Impedance: 10MΩ
Maximum Input: 1000V DC or 1000V AC RMS
AC Voltage (Auto-ranging)
Range Resolution Accuracy
400.0mV 0.1mV
4.000V 1mV ±1.0% of reading
40.00V 10mV ±3 digits
400.0V 100mV
1000V 1V ±1.2% of rdg ±5 digits
All AC voltage ranges are specified
from 5% of range to 100% of range
Input Impedance: 10MΩ
AC Response: 50Hz to 400Hz
Maximum Input: 1000V DC or 1000V AC RMS
DC Current (Auto-ranging)
Range Resolution Accuracy
400.0µA 0.1µA
4000µA 1µA ±1.2% of reading
40.00mA 10µA ±3 digits
400.0mA 100µA
10A 10mA ±2.5% of reading
±3 digits
