Jaycar QM1571 - AC Current (Auto-ranging)

www.procontechnology.com.au Phone: (03) 98306288
Overload Protection: FF500mAI1000V and F10A/1000V
Maximum Input: 400µA DC on µA range
400mA DC on mA range
10A DC on 10A range
AC Current (Auto-ranging)
Range Resolution Accuracy
400.0µA 0.1µA
4000µA 1µA ±1.5% of rdg ±5 digits
40.00mA 10µA
400.0mA 100µA
10A 10mA ±3.0% of rdg ±5 digits
All AC Current ranges are specified
from 5% of range to 100% of range
Overload Protection: FF500mA/1000V and F10A I 1000V
AC Response: 50Hz to 400Hz
Maximum Input: 400µA AC RMS on µA
400mA AC RMS on mA
10A AC RMS on 10A range
