Jaycar QM1571 - Resistance [Ω] (Auto-ranging); Capacitance (Auto-ranging)

www.procontechnology.com.au Phone: (03) 98306288
Resistance [Ω] (Auto-ranging)
Range Resolution Accuracy
400.00Ω 0.1Ω ±0.8% of rdg ±5 digits
4.000kΩ 1Ω
40.00kΩ 10Ω ±0.8% of rdg ±2 digits
400.0kΩ 100Ω
4.000MΩ 1kΩ ±2.5% of rdg ±8 digits
40.00MΩ 10kΩ
Input Protection: 1000V DC or 1000V AC RMS
Capacitance (Auto-ranging)
Range
Resolution
Accuracy
40.00nF 10pF ±5.0% of rdg ±7 dgts
400.0nF 0.1nF
4.000µF 1nF ±3.0% of rdg ±5 dgts
40.00µF 10nF
100.0µF 0.1µF ±5.0% of rdg ±7 dgts
Input Protection: 1000V DC or 1000V AC RMS
Frequency (Auto-ranging)
Range
Resolution
Accuracy
4.000Hz 0.001Hz
