Jaycar QM1571 - Frequency (Auto-ranging); Duty Cycle; Temperature

www.procontechnology.com.au Phone: (03) 98306288
40.00Hz 0.01Hz ±1.0% of rdg ±3 dgts
400.0Hz 0.1Hz
4.000kHz 1Hz
40.00kHz 10Hz
400.0kHz 100Hz
5.00MHz 1kHz ±1.2% of rdg ±4 dgts
Sensitivity: >0.5V RMS when ≤1MHz
Sensitivity: >3V RMS when >1MHz
Input Protection: 1000V DC or 1000V AC RMS
Duty Cycle
Range
Resolution
Accuracy
0.1%~99.9%
0.1% ±1.2% of rdg ±2 dgts
Pulse width: >100us, <1 00ms
Frequency: 5Hz to 150kHz
Sensitivity: <0.5V RMS
Overload protection: 1000V DC or AC RMS
Temperature
Range Resolution
Accuracy
-20
o
C ~ +760°C 1°C ±3% of rdg ±5
dgts
-4°F ~ +1400°F 1°F ±3% of rdg ±8
dgts
Sensor: Type K Thermocouple
